Deploy a Java Web App on Tomcat 8 with Habitat

September 7, 2016

Overview

We recently released a new Habitat Package for deploying JavaEE Web application on Tomcat 8. The best way to learn how to take advantage of this new package is with an example, so that’s what we’ll do in this post.

As part of this example, we’ll take the perspective of the Java application developer. We’ll make design decisions that are important to a developer, configure our plan in such a way that it best accommodates our developer-centric workflow, and still be able to provide all the automation necessary to deploy our application when handed off to other teams.

The following video is a companion to this article. You may find it helpful to watch the video first before diving into the details of this blog post.

Application Details

Our example application is a simple JavaEE Web application that renders a map of all the National Parks in the United States via a map. Users can browse the map, zoom in, and click on any park to get information about the park.

The application utilizes a MongoDB backend that contains the information about the National Parks. A jQuery front end handles the map rendering and calls to the RESTful backend.

As with most Java application, Maven is used to compile the source files into a WAR file suitable for deployment into Apache Tomcat or various other application containers.

Finally, the sample application is available on GitHub at https://github.com/billmeyer/national-parks.

Plan Files

Considerations

Choosing Habitat to deploy Java web applications has some great benefits worth considering:

The automation travels with the application.
- Application developers want to focus on writing applications and delivering business value in an efficient, streamlined manor. They don’t want to be encumbered by having to figure out the deployment details that extend beyond their own developer’s workstation.
- Infrastructure details like identifying the hostname/ip address of the web and database tiers, which environment (QA, UAT, Production) the app is running in are not primary concerns.
Having the application bundled with the automation needed to run the applications offers the ability to export that package into a variety of different runtime environments or be able to execute them natively.

`plan.sh`

Lets take a look at the plan.sh file that we’ll be using to package up our national-parks application.

We have a couple of requirements we want to meet as part of its design:

Because we are a Java developer, we want to be able to pull our source files straight from GitHub as opposed to making a source tarball and pushing it to a staging URL where it can be pulled from.
Our application layer needs to be able to find its database layer and we don’t want to have to hard-code hostname/port information in our configuration files. We want to take advantage of Habitat’s runtime binding to be able to locate our needed resources.

So, with these considerations in mind, we can begin to step through our plan.sh file.

Basic settings

    pkg_name=national-parks
    pkg_description="A sample JavaEE Web app deployed in the Tomcat8 package"
    pkg_origin=billmeyer
    pkg_version=0.1.3
    pkg_maintainer="Bill Meyer <bill@chef.io>"
    pkg_license=('Apache-2.0')
    pkg_source=https://github.com/billmeyer/national-parks
    pkg_deps=(core/tomcat8 billmeyer/mongodb)
    pkg_build_deps=(core/git core/maven)
    pkg_expose=(8080)
    pkg_svc_user="root"

The majority of these entries are self-explanatory. Worth noting are the following:

pkg_source – This is a required setting for Habitat. Typically this setting points to a URL where a tarball of the source code can be downloaded. However, since we are pulling our source from GitHub and because we cannot leave this setting blank (the build will fail if we do), we simply put the URL of the GitHub repository to keep Habitat happy.
pkg_deps – These are the runtime dependencies we have. In our example, we only need core/tomcat8 and billmeyer/mongodb. Its worth noting that because the Tomcat8 package is, itself, dependent upon core/jdk8, we do not need to declare a dependency on core/jdk8.
pkg_build_deps – These are the build dependencies needed to build our application. They are not needed at runtime so, by only declaring these as build dependencies, we shrink our resulting Habitat package and any other formats we may export to (e.g., a docker container).
pkg_expose – Because we are deploying a web app on Tomcat, we need access to Tomcat’s web connector on port 8080.

Callbacks

In the next section of plan.sh, we supply our own implementation of the available callbacks.

do_download()

We override the do_download() callback simply because we want to pull from GitHub:

    do_download()
    {
        build_line "do_download() =================================================="
        cd ${HAB_CACHE_SRC_PATH}

        build_line "\$pkg_dirname=${pkg_dirname}"
        build_line "\$pkg_filename=${pkg_filename}"

        if [ -d "${pkg_dirname}" ];
        then
            rm -rf ${pkg_dirname}
        fi

        mkdir ${pkg_dirname}
        cd ${pkg_dirname}
        GIT_SSL_NO_VERIFY=true git clone --branch v${pkg_version} https://github.com/billmeyer/national-parks.git
        return 0
    }

As you can see, this is as simple as creating a new package directory to store our source code in and cloning the appropriate repository from GitHub.

Note: as a matter of convention, our plan’s pkg_version matches a git tag we create in GitHub. This allows us to pull a specific release from GitHub that matches the version this plan file was written for.

do_clean() & do_unpack()

Next we provide our own implementation of do_clean() and do_unpack():

    do_clean()
    {
        build_line "do_clean() ===================================================="
        return 0
    }

    do_unpack()
    {
        # Nothing to unpack as we are pulling our code straight from github
        return 0
    }

Again, these are based on the fact that we are pulling from GitHub so we don’t want the default implementation to do anything.

do_build()

Next is the do_build() callback. We need to supply a version that will build our application using Maven:

do_build()
{
    build_line "do_build() ===================================================="

    # Maven requires JAVA_HOME to be set, and can be set via:
    export JAVA_HOME=$(hab pkg path core/jdk8)

    cd ${HAB_CACHE_SRC_PATH}/${pkg_dirname}/${pkg_filename}
    mvn package
}

We building via Habitat, we’ve declared our dependency on core/jdk8 and core/maven so we can ask Habitat for the location of these packages via the hab pkg path command.

For example, to set JAVA_HOME, we can ask Habitat where the JDK8 installation resides:

    [7][default:/src:0]# hab pkg path core/jdk8
    /hab/pkgs/core/jdk8/8u92/20160620143238

and set our _JAVA_HOME to point to it:

    export JAVA_HOME=$(hab pkg path core/jdk8)

do_install()

With the application source compiled into a WAR file, its time to copy the national-parks.war file to the Tomcat8 webapps directory. We do this by overriding the do_install() callback.

    do_install()
    {
        build_line "do_install() =================================================="

        # Our source files were copied over to the HAB_CACHE_SRC_PATH in do_build(),
        # so now they need to be copied into the root directory of our package through
        # the pkg_prefix variable. This is so that we have the source files available
        # in the package.

        local source_dir="${HAB_CACHE_SRC_PATH}/${pkg_dirname}/${pkg_filename}"
        local webapps_dir="$(hab pkg path core/tomcat8)/tc/webapps"
        cp ${source_dir}/target/${pkg_filename}.war ${webapps_dir}/

        # Copy our seed data so that it can be loaded into Mongo using our init hook
        cp ${source_dir}/national-parks.json $(hab pkg path ${pkg_origin}/national-parks)/
    }

Here we set a couple of local variables– one that references where our application war file resides and the other where the webapps directory exists in Tomcat. Then we simply copy the file over to Tomcat.

We also need to copy our national park seed data (national-parks.json) to install directory so we can load it into MongoDB when our application is initialized.

do_verify()

Lastly, we override the do_verify() callback because we are cloning out of GitHub and there is no source tarball to compare the sha sum to.

    do_verify()
    {
        build_line "do_verify() ==================================================="
        return 0
    }

Hooks

hooks/init

Now we can begin implementing the hooks we need to automate the deployment and configuration of our application.

Our application comes with seed data that we must load into our MongoDB instance. To do this, we supply our own hooks/init file that will use the mongoimport tool to load the data from our national-parks.json file:

    #!/bin/bash

    exec 2>&1

    echo "Seeding Mongo Collection"

    MONGODB_HOME=$(hab pkg path billmeyer/mongodb)

    source {{pkg.svc_config_path}}/mongoimport-opts.conf
    echo "\$MONGOIMPORT_OPTS=$MONGOIMPORT_OPTS"

    # billmeyer/mongodb requirement to run mongoimport properly :
    ln -s $(hab pkg path core/glibc)/lib/ld-2.22.so /lib/ld-linux-x86-64.so.2 2>/dev/null

    ${MONGODB_HOME}/bin/mongoimport --drop -d demo -c nationalparks --type json \\
        --jsonArray --file $(hab pkg path billmeyer/national-parks)/national-parks.json ${MONGOIMPORT_OPTS}

NOTE: the mongoimport-opts.conf file is NOT a configuration file from Mongo’s perspective, its a necessity on the Habitat side to get files in the /config directory to have their variable substitution at runtime. When Habitat runs an application, it will only look for file in the /config directory ending in a .conf extension. All other extensions will be ignored. Because we want to use Habitat’s Runtime Binding to enable us to locate our running MongoDB instance, we need to supply a file with a .conf extension so that Habitat will perform the variable substitution we need for runtime binding to work properly. Future releases of Habitat will hopefully remedy this.

hooks/run

We can now look at the hooks/run file which will be responsible for starting our application. In our case we simply start up Tomcat to run the application.

    #!/bin/bash

    exec 2>&1

    echo "Starting Apache Tomcat"

    export JAVA_HOME=$(hab pkg path core/jdk8)
    export TOMCAT_HOME="$(hab pkg path core/tomcat8)/tc"

    source {{pkg.svc_config_path}}/catalina-opts.conf
    echo "\$CATALINA_OPTS=$CATALINA_OPTS"

    exec ${TOMCAT_HOME}/bin/catalina.sh run

Runtime Configuration settings

With our hooks implemented, we can begin implementing the configurable settings we want to allow to be overridden at runtime.

Posts

config/mongoimport-opts.conf

As mentioned in the Considerations section, our application needs to be told where to find the hostname and port number where our MongoDB instance is running. Furthermore, we want to take advantage of Habitat’s Runtime Binding to have the Habitat Supervisor running MongoDB be able to share the hostname and port number when we start up our Tomcat instance as its peer.

As mentioned above, config/mongoimport-opts.conf isn’t a formal configuration file, but rather its a way we can build a file dynamically at runtime that we can then ‘source’ into our hooks/init script to supply the dynamically supplied values (in our case, the values for the MongoDB host and port) to mongoimport.

In this example, we start Tomcat with a command similiar to:

    $ hab start billmeyer/national-parks --peer 172.17.0.2 --bind database:mongodb.default

By doing this, we create a binding within our Habitat Supervisor with the name database that will be assigned all of the service group information that we are interested in. We can then access the elements of service group (ie., {{ip}} and {{port}}) to tell mongoimport where to connect to.

    {{~#if bind.has_database}}
    {{~#each bind.database.members}}
    export MONGOIMPORT_OPTS="--host={{ip}} --port={{port}}"
    {{~/each}}
    {{~/if}}

config/catalina-opts.conf

Like the config/mongoimport-opts.conf file above, we need to pass the database host and port via a Java Environment variable (-D) on the command line.

    {{~#if bind.has_database}}
    {{~#each bind.database.members}}
    export CATALINA_OPTS="-DMONGODB_SERVICE_HOST={{ip}} -DMONGODB_SERVICE_PORT={{port}}"
    {{~/each}}
    {{~/if}}

Tomcat will use the CATALINA_OPTS environment variable to push these -D values to the JVM where they can be read by our java code.

Packaging

With all of the necessary plan files authored, we can build our Habitat package.

NOTE: The entire Habitat Plan for this example can be pulled from GitHub:

    $ cd ~
    $ git clone https://github.com/billmeyer/national-parks-plan.git

Build the national-parks package

From our ~/national-parks-plan directory:

 On macOS, run:

     $ hab studio enter

 On Linux, run:

     $ sudo hab studio enter

Start the build

     [1][default:/src:0]# build
     : Loading /src/plan.sh
     national-parks: Plan loaded
     national-parks: hab-plan-build setup
     national-parks: Using HAB_BIN=/hab/pkgs/core/hab/0.9.0/20160815225003/bin/hab for installs, signing, and hashing
     national-parks: Resolving dependencies
     » Installing core/git
     ↓ Downloading core/git/2.7.4/20160729215550
     ...
     » Signing /hab/cache/artifacts/.billmeyer-national-parks-0.1.3-20160826185302-x86_64-linux.tar.xz
     ☛ Signing /hab/cache/artifacts/.billmeyer-national-parks-0.1.3-20160826185302-x86_64-linux.tar.xz with billmeyer-20160629135755 to create /hab/cache/artifacts/billmeyer-national-parks-0.1.3-20160826185302-x86_64-linux.hart
     ★ Signed artifact /hab/cache/artifacts/billmeyer-national-parks-0.1.3-20160826185302-x86_64-linux.hart.
     mkdir: created directory '/src/results'
     '/hab/cache/artifacts/billmeyer-national-parks-0.1.3-20160826185302-x86_64-linux.hart' -> '/src/results/billmeyer-national-parks-0.1.3-20160826185302-x86_64-linux.hart'
        national-parks: hab-plan-build cleanup
        national-parks:
        national-parks: Source Cache: /hab/cache/src/national-parks-0.1.3
        national-parks: Installed Path: /hab/pkgs/billmeyer/national-parks/0.1.3/20160826185302
        national-parks: Artifact: /src/results/billmeyer-national-parks-0.1.3-20160826185302-x86_64-linux.hart
        national-parks: Build Report: /src/results/last_build.env
        national-parks: SHA256 Checksum: a7ee5012ca1f30de87686f433cb5092baad1e7525249d73bdb3e527306305f8e
        national-parks: Blake2b Checksum: b0e2d83b411c302bf649bfbc7e53670e833ff75b808081e6e4837c7bc91c6803
        national-parks:
        national-parks: I love it when a plan.sh comes together.
        national-parks:
        national-parks: Build time: 13m17s

Once the build is complete, we have a Habitat package file that we can either run directly or export to other formats for our preferred runtime environment.

Execution

For this example, we want to export our application’s Habitat package into a Docker image that we can then run via docker. We also want to export the MongoDB package into a Docker image as well.

Export to docker

From within hab studio execute the following.

Export the MongoDB docker image.

     [2][default:/src:0]# hab pkg export docker billmeyer/mongodb
     core/hab-pkg-dockerize is not installed
     Searching for core/hab-pkg-dockerize in remote https://willem.__Habitat__.sh/v1/depot
     » Installing core/hab-pkg-dockerize
     ↓ Downloading core/hab-pkg-dockerize/0.9.0/20160815225538
         3.93 KB / 3.93 KB / [==================================================================================================================] 100.00 % 45.65 MB/s
     → Using core/acl/2.2.52/20160612075215
     → Using core/attr/2.4.47/20160612075207
     → Using core/bash/4.3.42/20160729192720
     ...
     Step 7 : ENTRYPOINT /init.sh
      ---> Running in 5bbb01fafc60
      ---> cac9aae3a725
     Removing intermediate container 5bbb01fafc60
     Step 8 : CMD start billmeyer/mongodb
      ---> Running in c0533ce06691
      ---> 53c5601a02c6
     Removing intermediate container c0533ce06691
     Successfully built 53c5601a02c6

Export the National Parks docker image

     [3][default:/src:0]# hab pkg export docker billmeyer/national-parks
        hab-studio: Creating Studio at /tmp/hab-pkg-dockerize-Nw3A/rootfs (baseimage)
     > Using local package for billmeyer/national-parks
     > Using local package for billmeyer/mongodb/3.2.6/20160824195527 via billmeyer/national-parks
     > Using local package for core/acl/2.2.52/20160612075215 via billmeyer/national-parks
     ...
     Step 7 : ENTRYPOINT /init.sh
      ---> Running in 364991c8ff8d
      ---> 6472464ba9c0
     Removing intermediate container 364991c8ff8d
     Step 8 : CMD start billmeyer/national-parks
      ---> Running in bf66f488ba62
      ---> 67dbaef2b854
     Removing intermediate container bf66f488ba62
     Successfully built 67dbaef2b854

From a new terminal (not in hab studio), verify the docker images exist by executing the following:

     $ docker images
     REPOSITORY                                  TAG                    IMAGE ID            CREATED             SIZE
     billmeyer/national-parks                    0.1.3-20160826185302   67dbaef2b854        3 minutes ago       710.7 MB
     billmeyer/national-parks                    latest                 67dbaef2b854        3 minutes ago       710.7 MB
     billmeyer/mongodb                           3.2.6-20160824195527   53c5601a02c6        8 minutes ago       303.2 MB
     billmeyer/mongodb                           latest                 53c5601a02c6        8 minutes ago       303.2 MB

You should see an entry for billmeyer/national-parks and one for billmeyer/mongodb.

Run the Application

From a terminal, execute the following:

     $ docker run -it -p 27017:27017 billmeyer/mongodb

NOTE: If you are running on Linux, run this command via sudo.

Port 27017 is what Mongo uses to listen for incoming connections so we tell docker to open that port up to external connections.

You will notice as it starts, the Habitat Supervisor displays its IP address:

     hab-sup(MN): Starting billmeyer/mongodb
     hab-sup(TP): Child process will run as user=root, group=hab
     hab-sup(GS): Supervisor 172.17.0.3: 84a8cbf3-839c-4ad5-bb13-4766e0e5432e
     hab-sup(GS): Census mongodb.default: fbf93825-d0e3-4866-bde0-56c29454abd1
     hab-sup(GS): Starting inbound gossip listener
     hab-sup(GS): Starting outbound gossip distributor
     hab-sup(GS): Starting gossip failure detector
     hab-sup(CN): Starting census health adjuster
     ...

172.17.0.3 in this example. We will need to pass it as our peer when we start up Tomcat in the next step.

From a new terminal, execute the following:
```
     $ docker run -it -p 8080:8080 billmeyer/national-parks --peer 172.17.0.3 --bind database:mongodb.default
```
We start the Tomcat instance and pass the ip address of our MongoDB peer along with a bind option to enable the runtime binding behavior we want to take advantage of as explained earlier.
```
     hab-sup(MN): Starting billmeyer/national-parks
     hab-sup(TP): Child process will run as user=root, group=hab
     hab-sup(GS): Supervisor 172.17.0.4: e57136c8-b1d4-4efe-b8e7-308cf33d15e7
     hab-sup(GS): Census national-parks.default: 564de0e4-d03f-4523-82b0-3d75346cf5fd
     hab-sup(GS): Starting inbound gossip listener
```
As the Tomcat supervisor starts, you can see it join its peer:
```
     hab-sup(GS): Joining gossip peer at 172.17.0.3:9634
```
hab-sup(GS): Starting outbound gossip distributor hab-sup(GS): Starting gossip failure detector hab-sup(CN): Starting census health adjusterWhen this happens, Habitat triggers a refresh of the files in our plan’s /config directory. As it updates, we can see confirmation of the update in the startup output:
```
     hab-sup(SC): Updated catalina-opts.conf
     hab-sup(SC): Updated mongoimport-opts.conf
     hab-sup(TP): Restarting because the service config was updated via the census
```
Next, our hooks/init script runs where we see positive confirmation that the dynamic runtime binding has been applied and that we do, in fact, have a configured IP address and Port available to use:
```
     init(PH): Seeding Mongo Collection
     init(PH): $MONGOIMPORT_OPTS=--host=172.17.0.3 --port=27017
```
Lastly, our init script loads our seed data into our MongoDB instance:
```
     init(PH): 2016-08-26T19:31:25.254+0000  connected to: 172.17.0.3:27017
```
init(PH): 2016-08-26T19:31:25.254+0000 dropping: demo.nationalparks init(PH): 2016-08-26T19:31:25.279+0000 imported 359 documentsAt this point, our hooks/run script takes over starting Tomcat as normal.

If you are running docker natively on Linux, you can point your browser directly at the IP address of your Tomcat instance:

     http://somehost:8080/national-parks

If you are running docker on macOS, you need to get the ip address from docker using a command like:

     $ open "http://$(docker-machine ip default):8080/national-parks"

Posted in:

Chef Habitat

Configure, Deploy, Manage

Enterprise Job Orchestration

Security and Compliance

Deploy a Java Web App on Tomcat 8 with Habitat

Overview

Application Details

Plan Files

Considerations

`plan.sh`

Basic settings

Callbacks

do_download()

do_clean() & do_unpack()

do_build()

do_install()

do_verify()

Hooks

hooks/init

hooks/run

Runtime Configuration settings

config/mongoimport-opts.conf

config/catalina-opts.conf

Packaging

Build the national-parks package

Execution

Export to docker

Run the Application

Bill Meyer

Categories

INTERNET US

Company

Using Chef

Legal

Connect with us

Configure, Deploy, Manage

Enterprise Job Orchestration

Security and Compliance

Achieving DevSecOps Success - Any Cloud to Any Edge

Featured Topics

My Account

Deploy a Java Web App on Tomcat 8 with Habitat

Overview

Application Details

Plan Files

Considerations

plan.sh

Basic settings

Callbacks

do_download()

do_clean() & do_unpack()

do_build()

do_install()

do_verify()

Hooks

hooks/init

hooks/run

Runtime Configuration settings

config/mongoimport-opts.conf

config/catalina-opts.conf

Packaging

Build the national-parks package

Execution

Export to docker

Run the Application

Bill Meyer

Categories

INTERNET US

Company

Using Chef

Legal

Connect with us

`plan.sh`
